| Overall Length |
1920mm |
| Overall Width |
790mm |
| Overall Hight |
1190mm |
| Wheel Base |
1240mm |
| Front Type |
2.25×17 |
| Rear Type |
2.50×17 |
| Front Suspension |
Telesonic inner Spring with Rebound Damping |
| Rear Suspension |
Swing Arm with Outer Spring Shocks with Rebound Damping & Preload Adjuster |
| Motor |
BLDC 72v/2HP Spoke HUB Motor |
| Controller |
72V/1500W with can (Controlled Area Network) |
| Battery |
High Power Lithium ion Battery 72v 24ah |
| Battery/Controller Cable |
Special Battery to Controller Cable with can communication Water IP 65 Standard |
| Charger |
72v Battery Charger with can Communication |
| Charger Time |
4 HRS to 5 HRS |
| Throttle |
Electronically Controlled through Wire/Sensor |
| Left Switch Assembly |
Left Lever Switch to Disconnect Current to Motor to Reduce Speed /Switch for Left-Right Signal. |
| Right Switch Assemble |
Drive Mode Switch 1-2-3 Head Light /Tail Light Switch, Lever Right Switch to Disconnect Motor Current While Braking. |
| Speedometer |
Digital Speedometer/Odometer /Trip Meter/Battery Level Gauge |
